BF – 2- and 3-way control valves, DN15-50, kvs 0.63-40, 20 mm stroke
Valves designed for control of hot, cold or glycol-mixed water in heating and ventilation systems. The valves are intended for use together with Regin’s RVAN5…/RVAN10… actuators.
Item
BF215-0.63
- Rangeability
- 100:1
- Stroke
- 20 mm
- Nominal diameter
- DN15
- Kvs
- 0.63 m³/h
- Max. diff. pressure
- 1600 kPa
- Connection
- G½"
- Media temperature
- -5…140 °C
- Valve Type
- 2-Way
BF315-0.63
- Rangeability
- 100:1
- Stroke
- 20 mm
- Nominal diameter
- DN15
- Kvs
- 0.63 m³/h
- Max. diff. pressure
- 1600 kPa
- Connection
- G½"
- Media temperature
- -5…140 °C
- Valve Type
- 3-Way
